Akumulatory domowe
TSYS-HS51
-
10,2 kWh-66,5 kWh
TSYS-HS51 oferuje szeroki zakres pojemności od 10,2 kWh do 66,5 kWh,, dzięki czemu jest odpowiedni do różnych potrzeb energetycznych. Jego kompatybilność z TCBox-70 pozwala na rozbudowę do 3 kolumn w celu zwiększenia pojemności.
-
Obejrzyj wideo
Zaleta produktu
TSYS-HS51 obsługuje prąd ładowania/rozładowywania do 70A, zapewniając szybki transfer energii. Dzięki ochronie IP66 gwarantuje niezawodną pracę w różnych środowiskach. System jest również wyposażony w opcjonalny przewód 2 w 1 do połączeń równoległych, co pomaga wydłużyć jego żywotność i zoptymalizować wydajność.
Assured Reliability
IP66 protection degree
LiFePO4 battery cell & high-performance processors
Aerosol fire suppression for precise protection
Smart Management
Remote fault diagnosis, upgrade and maintenance
Unique battery heating tech and wide temperature tolerance
Optional parallel connection using a two-in-one cable for easy capacity expansion and extend battery lifespan
Maximum 10% expansion of effective power over the entire life cycle to increase cycle life (optimizer version)
3-hour rapid equalization (optimizer version)
High Performance
10.2-66.5 kWh wide capacity range
Max. 70A charging / discharging current
Cycle life > 6000 times
Flexible Adaptability
Compatible with TCBox-70, up to 3 towers of batteries
Compact and stackable for easy installation
Supporting direct battery expansion
Supporting mixed use of new and old batteries, supports rapid capacity expansion, plug and play, no energy loss (optimizer version)
Parametry produktu
-
T-HS10.2-
SYSTEM SPECIFICATION
Number of modules 2 Rated energy 10.2 kWh Rated voltage 102.4 V Rated power 6.1 kW
Dimension (W x H x D) 600 × 621 × 376 mm -
GENERAL
BMS Dimensions (L × W × H) 600 × 225 × 376 mm BMS Weight 18.5 kg Battery type Li-ion (LFP) Module capacity 5.1 kWh Battery dimension (W x H x D) 600 × 168 × 376 mm Net weight 46 kg / 47.1 kg (with optimizer) -
GENERAL SPECIFICATION
Environment Outdoor / Indoor Protection degree IP66
-
-
T-HS15.3
-
SYSTEM SPECIFICATION
Number of modules 3 Rated energy 15.3 kWh Rated voltage 153.6 V Rated power 9.2 kW
Dimension (W x H x D) 600x789 x376 mm -
GENERAL
BMS Dimensions (L × W × H) 600 × 225 × 376 mm BMS Weight 18.5 kg Battery type Li-ion (LFP) Module capacity 5.1 kWh Battery dimension (W x H x D) 600 × 168 × 376 mm Battery weight 46 kg / 47.1 kg (with optimizer) -
GENERAL SPECIFICATION
Environment Outdoor / Indoor Protection degree IP66
-
-
T-HS20.4
-
SYSTEM SPECIFICATION
Number of modules 4 Rated energy 20.4 kWh Rated voltage 204.8 V Rated power 12.3 kW
Dimension (W x H x D) 600x957x376 mm -
GENERAL
BMS Dimensions (L × W × H) 600 × 225 × 376 mm BMS Weight 18.5 kg Battery type Li-ion (LFP) Module capacity 5.1 kWh Battery dimension (W x H x D) 46 kg / 47.1 kg (with optimizer) Battery weight 46 kg -
GENERAL SPECIFICATION
Environment Outdoor / Indoor Protection degree IP66
-
-
T-HS25.6
-
SYSTEM SPECIFICATION
Number of modules 5 Rated energy 25.6 kWh Rated voltage 256.0 V Rated power 15.4 kW
Dimension (W x H x D) 600 x 1125 x 376 mm -
GENERAL
BMS Dimensions (L × W × H) 600 × 225 × 376 mm BMS Weight 18.5 kg Battery type Li-ion (LFP) Module capacity 5.1 kWh Battery dimension (W x H x D) 600 × 168 × 376 mm Battery weight 46 kg / 47.1 kg (with optimizer) -
GENERAL SPECIFICATION
Environment Outdoor / Indoor Protection degree IP66
-
-
T-HS30.7
-
SYSTEM SPECIFICATION
Number of modules 6 Rated energy 30.7 kWh Rated voltage 307.2 V Rated power 18.4 kW
Dimension (W x H x D) 600x1293 x376 mm -
GENERAL
BMS Dimensions (L × W × H) 600 × 225 × 376 mm BMS Weight 18.5 kg Battery type Li-ion (LFP) Module capacity 5.1 kWh Battery dimension (W x H x D) 600 × 168 × 376 mm Battery weight 46 kg / 47.1 kg (with optimizer) -
GENERAL SPECIFICATION
Environment Outdoor / Indoor Protection degree IP66
-
-
T-HS35.8
-
SYSTEM SPECIFICATION
Number of modules 7 Rated energy 35.8 kWh Rated voltage 358.4 V Rated power 21.5 kW
Dimension (W x H x D) 600 x1461 x376 mm -
GENERAL
BMS Dimensions (L × W × H) 600 × 225 × 376 mm BMS Weight 18.5 kg Battery type Li-ion (LFP) Module capacity 5.1 kWh Battery dimension (W x H x D) 600 × 168 × 376 mm Battery weight 46 kg / 47.1 kg (with optimizer) -
GENERAL SPECIFICATION
Environment Outdoor / Indoor Protection degree IP66
-
-
T-HS40.9
-
SYSTEM SPECIFICATION
Number of modules 8 Rated energy 40.9 kWh Rated voltage 409.6 V Rated power 24.6 kW
Dimension (W x H x D) 600x1629x376 mm -
GENERAL
BMS Dimensions (L × W × H) 600 × 225 × 376 mm BMS Weight 18.5 kg Battery type Li-ion (LFP) Module capacity 5.1 kWh Battery dimension (W x H x D) 600 × 168 × 376 mm Battery weight 46 kg / 47.1 kg (with optimizer) -
GENERAL SPECIFICATION
Environment Outdoor / Indoor Protection degree IP66
-
-
T-HS46.0
-
SYSTEM SPECIFICATION
Number of modules 9 Rated energy 46.0 kWh Rated voltage 460.8 V Rated power 27.6 kW
Dimension (W x H x D) 600x957x376mm
+600x1125x376mm
-
GENERAL
BMS Dimensions (L × W × H) 600 × 225 × 376 mm BMS Weight 18.5 kg Battery type Li-ion (LFP) Module capacity 5.1 kWh Battery dimension (W x H x D) 600 × 168 × 376 mm Battery weight 46 kg / 47.1 kg (with optimizer) -
GENERAL SPECIFICATION
Environment Outdoor / Indoor Protection degree IP66
-
-
T-HS51.2
-
SYSTEM SPECIFICATION
Number of modules 10 Rated energy 51.2 kWh Rated voltage 512.0 V Rated power 30.7 kW
Dimension (W x H x D) 600x1125x376mm
+600x1125x376mm
-
GENERAL
BMS Dimensions (L × W × H) 600 × 225 × 376 mm BMS Weight 18.5 kg Battery type Li-ion (LFP) Module capacity 5.1 kWh Battery dimension (W x H x D) 600 × 168 × 376 mm Battery weight 46 kg / 47.1 kg (with optimizer) -
GENERAL SPECIFICATION
Environment Outdoor / Indoor Protection degree IP66
-
-
T-HS56.3
-
SYSTEM SPECIFICATION
Number of modules 11 Rated energy 56.3 kWh Rated voltage 563.2 V Rated power 33.8 kW
Dimension (W x H x D) 600x1293x376mm
+600x1125x376mm
-
GENERAL
BMS Dimensions (L × W × H) 600 × 225 × 376 mm BMS Weight 18.5 kg Battery type Li-ion (LFP) Module capacity 5.1 kWh Battery dimension (W x H x D) 600 × 168 × 376 mm Battery weight 46 kg / 47.1 kg (with optimizer) -
GENERAL SPECIFICATION
Environment Outdoor / Indoor Protection degree IP66
-
-
T-HS61.4
-
SYSTEM SPECIFICATION
Number of modules 12 Rated energy 61.4 kWh Rated voltage 614.4 V Rated power 36.9 kW
Dimension (W x H x D) 600x1293x376mm
+600x1293x376mm
-
GENERAL
BMS Dimensions (L × W × H) 600 × 225 × 376 mm BMS Weight 18.5 kg Battery type Li-ion (LFP) Module capacity 5.1 kWh Battery dimension (W x H x D) 600 × 168 × 376 mm Battery weight 46 kg / 47.1 kg (with optimizer) -
GENERAL SPECIFICATION
Environment Outdoor / Indoor Protection degree IP66
-
-
T-HS66.5
-
SYSTEM SPECIFICATION
Number of modules 13 Rated energy 66.5 kWh Rated voltage 665.6 V Rated power 39.9 kW
Dimension (W x H x D) 600x1461x376mm
+600x1293x376mm
-
GENERAL
BMS Dimensions (L × W × H) 600 × 225 × 376 mm BMS Weight 18.5 kg Battery type Li-ion (LFP) Module capacity 5.1 kWh Battery dimension (W x H x D) 600 × 168 × 376 mm Battery weight 46 kg / 47.1 kg (with optimizer) -
GENERAL SPECIFICATION
Environment Outdoor / Indoor Protection degree IP66
-
